PV Solar Plant
Fiambalá
In Operation
Fiambalá, department of Tinogasta, Catamarca province, Argentina. 1469msl.
Features
12MW
TOTAL INSTALLED POWER
30.092MWh
ESTIMATED ANNUAL GENERATION
8.441 homes
CAN SUPPLY ANNUALLY
18.401tn of CO2
PER YEAR ARE STOPPED FROM BEING EMITTED TO THE ATMOSPHERE
32.472 barrels
OF OIL PER YEAR, ARE REPLACED EQUIVALENTLY
11.000.000
DOLLARS + VAT WAS THE TOTAL INVESTMENT IN THE PROJECT
Characteristics of the region
Source: 3Tier
REGION:
ARID
AVERAGE ANNUAL TEMPERATURES:
14.3°C
AVERAGE ANNUAL RAINFALL:
90 TO 200MM
IRRADIANCE (GHI):
258.1W/M2 (2261KWh/M2/year)
Own Land.
40 hectares.
without prior exploitation.
Agreement with the Municipality.
Employment.
Around 100 people at the busiest time.
Construction Modality.
Own administration.
Logistics.
+ 130 containers of 40 feet.
PV Modules.
35,100 modules of 72 cell monocrystalline (340/345Wp).
Structure Type.
1 axis solar tracking.
Inverters and Power Transformer Stations.
3 inverter and transformation centers.
Connection to Grid.
ET Tinogasta 132kV.
Contract Conditions
Renewable Energy Sales Contract:
CAMMESA, awarded under RenovAr 1.5 tender
Term:
20 years
Nominal Price:
US$53.7
Commercial Enablement Date:
September 2018
